Double Agent W
Trans Black Flame Maple
Have you ever wanted the power and girth of a bridge humbucker, and the sweet/bluesy tone of a neck P-90 in one axe? Then this is your guitar. The two pickups complement each other perfectly, allowing you to switch seamlessly between two different tonal characters without losing volume or punch. And combined, they offer up a unique balls-meets-twang tone unlike anything else.
We design our own proprietary custom pickups, to achieve the best tonal match with our instruments. Reverend pickups are also specifically designed for each position, for balanced volume and tone when switching.
ROASTED MAPLE NECK
Roasted Maple is heat treated at over 300° F to remove sugars, moisture, and impurities. This maple is lighter, more stable, and has a beautiful caramel color. The result is an exceptional maple neck that will require less seasonal adjustment, and boasts a rich vintage look!
Korina (aka White Limba) is a medium-light weight wood, highly prized for consistency and tonal qualities. Often found in boutique and vintage instruments, all Reverends feature Korina bodies. A highly resonant wood, Korina is a key factor to producing our lively, responsive instruments that are rich in harmonics.
This passive bass roll-off is great for tightening up the low end, or re-voicing the pickups. It can make a humbucker sound like a single-coil, or give a P-90 that classic twang. Variable pickup voicing at your fingertips!
A thumbwheel under the tuner pushes a steel pin up through the post, locking the string in place for exceptional tuning stability and super-fast string changes.
Every Reverend is hand initialed on the back of the headstock by Zack Green, our highly skilled technician who sets up, inspects, and tests every instrument.
WILKINSON WVS50 IIK TREMOLO
Features include saddles that lock to the baseplate, adjustable arm swing tension, and a push-in/no freeplay arm. Combined with our boneite nut and pin-lock tuners, it stays in tune even under aggressive whammy action.
VARI-CLAW TREMOLO CLAW
This innovative claw gives you the option of 3 springs in the middle for a firm tremolo feel, or 2 springs on the outside for a softer feel. The offset hook design lets you switch between 3 or 2 springs, with little or no cumbersome adjustment of the claw needed.
CUSTOM DOME KNOBS
Our proprietary knobs feature a lower profile which is less likely to be accidentally hit by the player’s hand, and the white dot lets you easily see where your knob rotation is set.
We use “Boneite,” a synthetic bone nut, that is more consistent than natural bone, on all Reverend instruments. It reduces friction, allowing the strings to slide through the nut slots smoothly, improving tuning stability.
TRIPLE-TREE STRING TREE
This patent-pending string tree has an extended bar to hold down three strings at a time with just one tree, eliminating G string buzz in the nut slot.
DUAL-ACTION TRUSS ROD
Our dual action rod adjusts in both directions, allowing back bow or forward bow. This assures correct adjustment range is possible regardless of string tension, extreme climate conditions, or the effects of long term aging. It’s also located at the headstock for easy access.
SIX-BOLT NECK PLATE
Two extra bolts increase mounting pressure of the neck by fifty percent. This makes a stronger neck connection, which improves sustain, tuning stability, and neck alignment.
ANGLED NECK HEEL
All Reverend solidbody guitars in the Bolt-On series feature a low profile, angled neck heel. This improves comfort and hand access when you’re reaching for those high notes!
CUSTOM JACK PLATE
Our proprietary jack plate features four mounting screws, instead of two. The extra screws prevent the plate from tearing out of the body. Made of steel for durability, the laser etched logo adds an extra touch of class!
PURE TONE JACK
All Reverends use an upgraded jack by Pure Tone Technologies. A standard jack has single contacts, but the Pure Tone jack has dual contacts for improved grip, audio signal and reliability. The most dependable guitar jack available.
TREBLE BLEED CIRCUIT
All Reverend guitars have a treble bleed circuit, preserving the treble when you roll back the volume control. When you roll back a standard volume control, the tone loses treble and becomes dull sounding. Now you can turn down and still sound great!
We use Alpha control pots with a +-10% rating. While a typical pot is +-20%, our pots are built to tighter specifications, making them more consistent. Typically used in expensive boutique guitars, but standard issue in all Reverends.
10% POLY CAPS
We use caps with a +-10% rating, while a typical cap is +-20%. Our caps are made to tighter specifications, so they’re more consistent. Made of polyester, they’re also longer lasting, and less affected by temperature than cheaper ceramic caps . Typically used in expensive boutique guitars.
